ION Fast Ethernet Remotely Managed NID Module 10/100/1000Base-T to 100Base-FX with OAM/IP-Based Management

ION Fast Ethernet Remotely Managed NID Module 10/100/1000Base-T to 100Base-FX with OAM/IP-Based Management

The ION C2220 is a managed Network Interface Device (NID) module that provides an interface between 10/100/1000Base-T ports and 100Base-FX ports, allowing users to manage their links while integrating fiber optic cabling into 10/100/1000 copper environments

Description

The ION C2220 is a managed Network Interface Device (NID) module that provides an interface between 10/100/1000Base-T ports and 100Base-FX ports, allowing users to manage their links while integrating fiber optic cabling into 10/100/1000 copper environments. As a remotely manged device, the C2220 can be managed individually via an IP address or it can be managed by the ION Management Module when installed in a managed ION chassis. With advanced features like IEEE 802.3ah Link OAM, VLAN, QoS, SSH/SSL, jumbo frame support, and bandwidth allocation, the C2220 provides various methods for secure delivery of Ethernet services in business and mobile backhaul applications.

Additional information

Key Features

MEF 9, 14 + 21 certified
IEEE 802.3ah Link OAM
10K Jumbo Frame Support
Two selectable Remote management modes:
IP-Based Remote Management
In-Band (remote device managed by local peer)
Auto-MDI/MDIX
Auto-Negotiation
Pause
Link Pass Through
Far-End-Fault (FEF)
Remote Loopback
Field Upgradeable Firmware
IEEE 802.1p QoS Packet Classification
IEEE 802.1q VLAN and double VLAN tagging with 4096 VIDs
DHCP client
SNTP
TFTP
RADIUS client
RMON counters for each port
Bandwidth profiling
DMI Optical Management
Cable diagnostic function for copper ports
SSH
Telnet
Command Line Interface (CLI)
Web management
Focal Point management
SNMP v1, v2c, and v3
USB port for basic setup
Management VLAN
