Supports Jumbo Frame up to 10240 bytes
Authentication – RADIUS IEEE 802.1X, TACACS+
Security – Support SSH/SSL
Port security: MAC addresses to ports
Port based or tagged (IEEE 802.1Q) VLAN, MAC based VLAN, Management VLAN and Private VLAN Edge
DHCP Server, Client, Relay
IEEE 1588v2 PTP (TC)
ACLs Support for up to 512 entries, drop or rate limitation based on source and destination MAC, VLAN ID or IP address, protocol, port, DSCP/IP precedence, TCP/IP source and destination ports, IEEE 802.1p priority, Ethernet Type / IGMP packets, TCP flag
LLDP (Link Layer Discovery Protocol)
IEEE 802.3az Energy Efficiency
Web Management, SNMP V1/V2c/V3, Telnet, CLI
Supports IEEE 802.3ad port trunk with link aggregation control protocol (LACP). Supports up to 26 groups with up to (16) ports per group.
Supports IGMP Snooping V1/V2/V3, up to 1024 multicast groups, GVRP, IGMP Proxy, IGMP Querier
MLD snooping V1/V2: deliver IPv6 multicast packages only to the required receivers
Supports 8 hardware queues, Strict priority and WRR. Queue assignment based on DSCP and IEEE 802.1p CoS; IPv4/IPv6 precedence/ Type of Service / DiffServ / classification and remarking ACLs; rate limiting, ingress policer, egress shaping and rate control
IEEE 802.1s MSTP, IEEE 802.1w RSTP and IEEE 802.1D STP Compliant
Firmware Update, configure backup/restore through web GUI and TFTP
Supports IPv4/IPv6 Layer 3 static routing
ITU-T G.8031, G8032, loop detection

PoE Features

Compliant with IEEE 802.3at PoE+
Compliant with IEEE 802.3af PoE
IEEE 802.1AB LLDP-MED Configuration
Auto Power Reset
DHCP per port

Device Management System (DMS)

Graphical Monitoring – Topology view, Floor view, Map view
Traffic Monitoring
Troubleshooting – Network diagnostic, protection mechanism, performance and link management
