Managed Hardened Fast Ethernet Switch (16) 10/100Base-TX Ports + (2) 10/100/1000Base-X SFP/RJ-45 Combo Ports

Description

The SISTM1040-262D-LRT-B switch is a (16) port managed hardened switch with (2) copper ports or (2) dual speed SFP slots supporting Fast Ethernet to Gigabit Ethernet speeds. The (2) SFP slots provide the ultimate flexibility by allowing SFP fiber connections at different speeds and at a variety of communication distances. The ports can also be used in a redundant ring for maximum network reliability.

Additional information

Key Features	Auto-Negotiation Auto-MDI/MDIX Combo SFP ports support 100/1000Base-X SFPs Extended Operating Temperature (-40°C to +70°C) Dry Contact Relay Alarm Output Dual, Redundant, Auto-Sensing 12-48 VDC Power Inputs Overload Current Protection DIN Rail Mounting and Wall Mount Brackets Included PTP- Precision Timing Protocol RMON Port Based VLAN (4096) IEEE 802.1Q Tag VLAN GVRP Port Trunk with LACP QoS (Quality of Service) IEEE 802.1p Class of Service, Per port provides priority queues Port Based, Tag Based and Type of Service Priority Port Security: MAC address entries/filter IP Security: IP address security management to prevent unauthorized intruder Login Security: IEEE 802.1X/RADIUS Authentication IGMP Query mode for Multi-Media Application IGMP Multicast groups 1024 Support 0-ring and multi-ring, STP, RSTP, MSTP Provide redundant backup feature and recovery time below 20ms. SNMP v1 v2c, v3/Web/Telnet/CLI DHCP Client/DHCP Server TFTP Firmware Upgrade TFTP Configuration Backup/Restore IPv4/IPv6 dual-stac
Website	https://www.lantronix.com/products/sistm1040-262d-lrt-b-2/

Key Features

Auto-Negotiation
Auto-MDI/MDIX
Combo SFP ports support 100/1000Base-X SFPs
Extended Operating Temperature (-40°C to +70°C)
Dry Contact Relay Alarm Output
Dual, Redundant, Auto-Sensing 12-48 VDC Power Inputs
Overload Current Protection
DIN Rail Mounting and Wall Mount Brackets Included
PTP- Precision Timing Protocol
RMON
Port Based VLAN (4096)
IEEE 802.1Q Tag VLAN
GVRP
Port Trunk with LACP QoS (Quality of Service)
IEEE 802.1p Class of Service, Per port provides priority queues
Port Based, Tag Based and Type of Service Priority
Port Security: MAC address entries/filter
IP Security: IP address security management to prevent unauthorized intruder
Login Security: IEEE 802.1X/RADIUS Authentication IGMP Query mode for Multi-Media Application
IGMP Multicast groups 1024
Support 0-ring and multi-ring, STP, RSTP, MSTP
Provide redundant backup feature and recovery time below 20ms.
SNMP v1 v2c, v3/Web/Telnet/CLI
DHCP Client/DHCP Server
TFTP Firmware Upgrade
TFTP Configuration Backup/Restore
IPv4/IPv6 dual-stac

Website

https://www.lantronix.com/products/sistm1040-262d-lrt-b-2/
