Store-and-Forward Architecture with 24 Gbps Switching Bandwidth
Supports Jumbo frames up to 9.6K Bytes
Ring Protections
Industry standard G.8032 Ethernet Ring Protection Switching (ERPS)
Support G.8031 Ethernet Linear Protection Switching (EPS)
Rapid Ring with recovery time less than 20ms
Supports LLDP Protocol
Temperature Detection and Alarm
Support HW Watchdog to resume operation from CPU hang up
IEEE 1588 v2 PTP
Port Mirroring
Power-over-Ethernet
Port Configuration
Auto Power Reset (APR)
DHCP per Port
Always on PoE
PoE Scheduling
Complies to IEEE 802.3at, IEEE 802.3af
IEEE 802.3ad LACP, up to 6 groups and up to 4 ports per group
Up to 4K VLAN groups, Port based, IEEE 802.1Q tag, Q-in-Q, MAC based VLAN, Management VLAN, Private VLAN Edge, Voice VLAN, GVRP
ACL – up to 256 entries, Drop or Rate limiting based on: Source and Destinations MAC, VLAN ID and IP address, protocol, port, DSCP/ IP precedence, TCP/UDP source and destination ports, IEEE 802.1p priority, Ethernet type, ICMP packets and TCP flag
Loop Protection
Quality of Service
Supports 8 hardware queues
Scheduling: strict priority and WRR, Queue assignment based on DSCP and class of service
Classification: Port based, IEEE 802.1p VLAN priority based, IPV4/IPV6 precedence / DSCP based, DiffServ, Classification and re-marking ACLs
Rate limiting: Ingress policer, Engress shaping and rate control, per port
IPv4/IPv6 dual stacks and static routing
Port Security, IP Source Guard
System Alarms via SYSLOG / SNMP Trap
DHCP Client/Server, DHCP relay, Option 82
Port based network access control (IEEE 802.1X)
Web / SNMP v1,v2c,v3 / Telnet / CLI management
Media Redundancy Protocol (MRP)
